T-213 TRANSFORMER WINDING DC RESISTANCE TEST SET

T-213 transformer winding resistance tester can test transformer, mutual inductor, reactor, dc resistance of motor and perceptual load. Instrument is small in size, light weight, strong function, easy operation, designed for production test and field measurement field staff . Large screen LCD in English and Chinese , Especially suitable for continuous the points contact load switch does not block the test , Dynamic measurement process , give an automatic arc suppression instructions alarm, Can edit the user information, test records can save and print. It can be configured PC online communication and testing capabilities.

Request a quote Download Catalogue video

APPLICATION

■ Universities;

■ Power plant;

■ Research institutes;

■ Electrical testing center;

■ Voltage transformer factory;

■ Transformer manufacturers;

■ Railway electrical department;

■ ISO17025 Electrical laboratory;

■ Electricity power bureau & power company;

■ Power engineering commissioning company;

■ Electrical Department of industrial and mining enterprises;

FEATURES

■ Easy to operate;

■ Data download by U disk;

■ Designed for rugged field use;

■ High power, with 12m test cable;

■ With 5.7 inch green LCD display;

■ Wide measuring range 1mΩ-20kΩ;

■ Automatic demagnetization function;

■ Communication:with RS232 and USB port;

■ Portable and lightweight, weighs only 7 kg;

■ Print :with internal installed 58mm wide thermal printer;

■ Measures transformer, mutual inductor, reactor, dc resistance of motor and perceptual load etc;

PARAMETERS

Electrical parameters
Power supply Single phase AC 220V±10% or 110V±10%, 50/60HzAC
Cooling way intermittent air cooled
Current output 10mA, 100mA, 1A, 5A, 10A, 20A.
Test voltage DC 28V
Test range 1mΩ-1Ω (20A)
1mΩ-2Ω (10A)
1mΩ-4Ω (5A)
100mΩ-20Ω (1A)
10Ω-200Ω (100mA)
100Ω-20kΩ (10mA)
Accuracy 0.1%±2bit
Resolution 0.1μΩ
Max storage volume 200 SETS
LCD 5.7″black and white LCD display
Key 3PCS
Test Cable 12m
Communication RS232 and USB communication interface
Printer internal installed 58mm wide thermal printer.
Test method Four fire
Degree of protection IP65
Standard DL/T 596-1996, DL/T967-2005, JJG166-1993, JJG724-1991,
IEC61010-1, IEC61326-1,GB6587.1-86
Mechanical parameters
Dimension (L×W×H) (mm) 415x319x168
Weight (kg) 7
Environmental conditions
Operating temperature -20°C to 50°C
Storage temperature -40°C to 70°C
Relative humidity ≤85%RH
